| Tested and Certified by WQA
to NSF / ASCI Standard 44 for Water Softeners and 372 for "lead
free" compliance.
PARTS INCLUDED
The Water Softening System should have the following parts:
1. Softener Tank with Valve and Bypass
2. Connector Kit
3. Drain Line Flow Control and Drain Fitting
4. Drain Line Tubing (shipped inside the salt tank)
5. Tubing Clamp
6. Wall Transformer
7. Instruction Manual
NOTE: Do not return the system to the store. Call First
Before starting to assemble the system, check that all the parts are present and not damaged.
The plumbing pieces needed to connect the water system and softener salt are not included. |
| System Specifications |
| Item Number |
4001557 |
4001558 |
4001559 |
| Part Number |
OMNI OM26KCS |
OMNI OM32KCS |
OMNI OM36KCS |
| Recharge Style |
Meter - Demand |
Meter - Demand |
Meter - Demand |
| Media Tank Size |
9" x 35" |
10" x 35" |
10" x 35" |
| Resin Volume |
0.82 Cu Ft |
1.00 Cu Ft |
1.09 Cu Ft |
| Salt Storage |
220 lbs |
220 lbs |
220 lbs |
| Drain Water Rate |
2.7 GPM |
3.9 GPM |
3.9 GPM |
| Service Connection Size |
1" NPT |
1" NPT |
1" NPT |
| Drain Connection Size |
1/2" NPT |
1/2" NPT |
1/2" NPT |
| Recharge (brine) Connection Size |
3/8" NPT |
3/8" NPT |
3/8" NPT |
| Installation Space Requirements |
23" D x 13" W x 45" H |
23" D x 13" W x 45" H |
23" D x 13" W x 45" H |
| Shipping Weight |
82 Lbs |
93 Lbs |
100 Lbs |
| |
|
|
|
|
